Monoblock prestressed concrete sleepers for track machines.

Prestressed concrete sleepers of several lengths and each one with the necessary elements to hold the late in a different position with the purpose of achieving the geometry of the track of the relevant machine.

PRECON has supplied of date more than 1,000,000 of lineal meters of sleepers for track machines. It is the only manufacturer supplying all the models in use in Spain.

It has supplied through its Spanish clients sleepers for track machines to Algeria, Argentina, Colombia, Turkey and Venezuela. The various parameters of design and the fasteners of the models supplied can be seen in the models table.

Sleepers of High Speed machines.
Sleepers of High Speed machines.
Sleepers for the expanding machine (Alegría Workshop Project)
Sleepers for the expanding machine (Alegría Workshop Project)
Turnout sleepers for a track with two simultaneous gauges (DF Rail Project)
Turnout sleepers for a track with two simultaneous gauges (DF Rail Project)

Sleepers model for track machines.


The sleepers can be supplied for track over ballast, track on rigid or elastic slab and sleepers with pads underneath. The worst design combination is 22.5 t and 200km/h and spokes between 90 and 17,000 m.



ON BALLAST
Model Fixing Application
4H-W WF Type High speed - Conventional
4H-V Vape 25-140 Conventional
3H-V Vape 22-130 Metro
3H-S SDU 9A-PA Conventional



SLAB TRACK
Model Fixing Application Elasticity
Monolithic WF Type High speed - Conventional Fastening
Trapezoidal cup Vape 25-140 High speed - Conventional Elastomer under sleeper
Sunken cup Vape 22-130 Metro  Elastomer under sleeper
